| Frame |
Carbon Frame,
120mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fork |
Fox 34SL Performance
Float, Grip 2, 130mm, 44mm offset |
| Rear
Shock |
Fox Float SL
Performance, 190x45mm, standard |
| Headset |
FSA No 42/48ACB
Integrated Headset, Tapered 1-1/8" - 1.5" |
| Grips |
WTB Wavelength |
| Handle
Bar |
Norco 6061, 760
(S1,S2,S3) 780mm (S4,S5), 20mm rise |
| Stem |
Norco 6061, 50mm,
35mm Clamp |
| Seat
Post |
TranzX YSI36, 31.6mm,
120mm (S1, S2) -150mm (S3) -170mm (S4) - 200mm (S5) |
| Seat Post
Clamp |
Norco bolted, 34.9mm
ID |
| Saddle |
WTB Silverado Medium |
| Front
Brake |
Shimano Deore MT520,
4-Piston, Metallic Pads |
| Front Brake
Rotor |
Shimano SM-RT64,
180mm, C-lock |
| Rear
Brake |
Shimano Deore MT520,
4-Piston, Metallic Pads |
| Rear Brake
Rotor |
Shimano SM-RT64,
180mm, C-lock |
| Shifter
Rear |
Shimano Deore XT
SW-M8250 Di2 |
| Rear
Derailleur |
Shimano Deore XT
RD-M8250 Di2, 12sp, SGS |
| Cassette |
Shimano Deore
CS-M6100-12, 10-51T, 12sp |
| Chain |
Shimano Deore
CN-M6100-12, 12sp |
| Crankset |
Shimano Deore
FC-M6120, 32T, CL55, 165mm (S1) 170mm (S2,S3) 175mm (S4,S5) |
| Bottom
Bracket |
Shimano BB-MT501, BSA
73mm |
| Front
Hub |
Shimano Deore HB-TC500, 15x110mm Boost, 32H,
C-lock |
| Rear Hub |
Shimano Deore
FH-TC500, 12x148 Boost, Micro Spline, 32H, C-lock |
| Rear Hub
Skewer |
148mm x 12mm TA, L174, TL13, M12x1.4 |
| Spokes/Nipples |
Stainless steel |
| Rims |
Stans Arch D, 28mm
ID, 32H, 29" |
| Front
Tire |
Maxxis Forekaster, 3C
MaxxTerra EXO, 29x2.40" |
| Rear
Tire |
Maxxis Rekon, 3C
MaxxTerra EXO, 29x2.40" |
| Sealant |
Stans 250ml sealant |
| Valves |
Stans tubeless
valves |
| Weight |
12.27
kg (27 lbs) |
| Weight Size |
S3 |
